Electrical Panel Inspection Checklist — Advanced Edition

Full site electrical audit for engineering firms, consultants and compliance engineers. 10 comprehensive sheets including thermographic records, protection relay settings, 100-row defect register, IEC 60364 / BS7671 compliance certificate and an executive summary dashboard.

What You Get — 10 Sheets

• 01 - Instructions — Comprehensive 9-step setup guide
• 02 - Panel Register — Unlimited panels — full site register with all details
• 03 - Visual Inspection — 60 items across 6 categories — industrial and HV panel ready
• 04 - Measurements — Full suite: voltage, current, IR, earth, loop impedance, PSCC and harmonics
• 05 - Protection Devices — 50-row device log with trip curves, settings and operation tests
• 06 - Thermographic Record — Infrared scan log with delta-T, severity rating and actions
• 07 - Protection Relay Log — OC, EF, differential relay settings and test results
• 08 - Defect Register — 100 rows with C1/C2/C3 severity coding and close-out tracking
• 09 - Compliance Certificate — IEC 60364 / BS7671 format — print-ready for regulatory submission
• 10 - Executive Summary — Dashboard with KPI boxes, panel results table and recommendations

Standards

IEC 60364 / BS7671 / NFPA 70E — suitable for industrial, commercial and infrastructure installations.

Format: Microsoft Excel (.xlsx) — instant download after purchase

Single-user non-transferable licence. © 2026 Build Smart Digital.
